Square Stand Technical Specifications

Compatibility
Stand for 10.2” and 10.5” iPads

Stand for 10.2” and 10.5” iPads
iPad (8th generation 2020)
iPad (7th generation 2019)
iPad Air (3rd generation 2019)
iPad Pro 10.5”

In the box
Included with Square Stand
Square Stand box contents illustration
  • Square Stand
  • Square Reader for contactless and chip & PIN cards
  • Dock for Square Reader
  • Micro USB cable
  • Power adapter cable
  • USB Hardware hub
  • Power adapter
  • Adhesive mount
  • Drill mount
Accepts
Card payments

Magnetic stripe and chip & PIN cards
EMV chip & PIN cards

Contactless payments

Contactless payments
Contactless cards, Apple Pay, Google Pay, Samsung Pay

Dimensions
Dimensions and measurements for Square Stand
Square Stand - Dimensions and measurements

Square Stand:
Height: 9.52 in. (242 mm)
Width: 11.07 in. (281 mm)
Depth: 7.75 in. (197 mm)

Square Reader:
Height: 0.4 in. (10 mm)
Width: 2.6 in. (66 mm)
Depth: 2.6 in. (66 mm)

Dock for Square Reader:
Height: 1.67 in. (42 mm)
Width: 2.82 in. (72 mm)
Depth: 3.1 in. (79 mm)
Attached USB cable: 5 ft. 10 in. (1.8 m)

Cable Length:
Stand to USB hub: 4 ft. (1.2 m)
Stand to wall outlet: 15 ft. (4.57 m)

Countertop space

13.86 in. (352 mm) circle required for stand to rotate fully

Processing fees

2.65% for all major credit cards
10¢ per INTERAC chip & PIN or tap

No monthly fees and no long-term commitments. Custom rates available for businesses that process $250k+ in credit card sales annually.

Contact sales to talk about custom rates ›
Learn more about payments ›

Software
Square Stand point of sale software options

Free, powerful software to run any business.
Square has a variety of POS options to best support you and your unique business needs. Stand supports all Square point of sale solutions.

Learn about Square Point of Sale ›
Learn about Square Appointments ›
Learn about Square for Restaurants ›
Learn about Square for Retail ›

Connectivity
Square Stand USB hardware hub

USB hardware hub
Connect up to three USB-compatible accessories with the included USB hardware hub.

Power modes

Plugged in
Stand is plugged into the power adapter and wall outlet and will simultaneously charge the iPad.

Wireless
Stand is unplugged and runs on the iPad’s battery power. Square Reader must be connected via Bluetooth to accept chip & PIN and tap payments. USB accessories are not supported in this mode.

Reader + Dock
Plug the dock into the Square Stand USB hub to keep Square Reader charged throughout the day.

Weight

Square Stand: 2,240 g
Square Reader: 56 g
Dock for Square Reader: 412 g

Materials

Metal
Moulded plastic

Colour

Glossy white

Mounting options

Drill mount or adhesive mount (Square Stand only)

Accessories

Square Stand is compatible with a wide range of third-party hardware accessories, like receipt printers and barcode scanners.

Shop accessories for Square Stand ›
See all accessories you can connect to Square hardware ›

Support

Square Stand is covered by a one-year limited warranty. Plus, you can get free help from our customer support team. Access the Square Stand guide for handy tutorial videos and common troubleshooting steps, or get in touch with our product specialists.
